Radiotehnika i èlektronika

The journal publishes articles on a wide range of theoretical and applied problems of radio electronics, communications and physical electronics, including original articles by leading scientists and specialists working in these fields, as well as materials prepared by major research centers. Subject headings of the journal cover all major areas of radio engineering and electronics, such as electrodynamics, the theory of propagation of radio waves, signal processing, transmission lines, theory and technology of communication, physics of semiconductors and physical processes in electronic devices, the use of radio electronics and radio electronic devices in biology and medicine, microelectronics, nanoelectronics, electron and ion emission, etc.

Media registration certificate: № 0110180 от 04.02.1993

Current Issue

Open Access Open Access  Restricted Access Access granted  Restricted Access Subscription Access

Vol 69, No 12 (2024)

Cover Page

Full Issue

Open Access Open Access
Restricted Access Access granted
Restricted Access Subscription Access

ЭЛЕКТРОДИНАМИКА И РАСПРОСТРАНЕНИЕ РАДИОВОЛН

Simple model for calculation of radiation parameters of a unidirectional flat openingv
Ostashev V.E.
Abstract

A model for calculating the radiation parameters of a flat aperture in the far zone of free space is described. The electromagnetic field on the aperture is specified by the field of the primary polarized wave emanating from the excitation point. The radiating system is represented by Huygens elements. Verification of the reliability of the calculation result is carried out at the level of agreement with fundamental physical principles, with analytical calculations, and with the experimental results. When the antenna is excited by an arbitrary electric pulse, the calculation time of the radiation parameters in the time, space, and frequency domains is a few minutes. The calculation model is equipped with an interface in the style of MS Windows.

Radiotehnika i èlektronika. 2024;69(12):1139-1149
pages 1139-1149 views
Surface electromagnetic fields of cladding modes of coreless optical fibers
Abel’mas M.A., Ivanov O.V.
Abstract

The exact hybrid modes of a coreless optical fiber are calculated. Spatial distributions of electromagnetic fields near the cladding surface are obtained. A comparison of radial, azimuthal, and longitudinal field components near the cladding surface is performed for the hybrid exact modes and approximate linearly polarized (LP) modes. The polarization characteristics of the modes are studied taking into account the longitudinal field component depending on the type of hybrid modes and mode numbers. The combination of hybrid modes forms modes similar to LP modes, which have an almost uniform linear polarization inside the fiber far from the cladding surface. It is shown that under the cladding surface the polarization of LP-like modes is also linear, but significantly non-uniform in azimuthal angle with a deviation of the polarization angle by up to 21о from the main direction of mode polarization. In addition, the role of the longitudinal field component near the cladding surface increases significantly, where its value can exceed the values of the transverse components.

Radiotehnika i èlektronika. 2024;69(12):1150-1161
pages 1150-1161 views

АНТЕННО-ФИДЕРНЫЕ СИСТЕМЫ

On the synthesis of anisotropic Luneburg lenses
Kaloshin V.A., Chung B.V.
Abstract

Two methods for synthesizing Luneburg lenses based on an inhomogeneous anisotropic dielectric are proposed: using an iterative procedure and a gradient medium model, as well as using a recurrent procedure and a layered medium model. As an example of the application of the proposed methods, a synthesis of two variants of a cylindrical Luneburg lens based on a ring dielectric structure was carried out. It is shown that the method based on the iterative procedure is unstable at small values of the radius. Using numerical modeling by the finite element method, an analysis of two versions of lens antennas based on cylindrical Luneburg lens synthesized using a layered dielectric model and a recurrent procedure is carried out.

Radiotehnika i èlektronika. 2024;69(12):1162-1169
pages 1162-1169 views

ТЕОРИЯ РАДИОТЕХНИЧЕСКИХ ЦЕПЕЙ

Perveance of cubic circuit containing Child-Langmuir diods in its edges
Dubinov A.E.
Abstract

A non-linear electric circuit in a cube-like form is studied. Similar Child–Langmuir diodes are connected in its edges. The procedure of the circuit decomposition by the method of equivalent nodes is carried out. As a result, an exact formula of the general circuit purveyance was derived. The formula can be used to estimate volt-ampere characteristic (VAC) of tetragonal networks with cubic elementary cells containing Child–Langmuir diodes.

Radiotehnika i èlektronika. 2024;69(12):1170-1174
pages 1170-1174 views

РАДИОФИЗИЧЕСКИЕ ЯВЛЕНИЯ В ТВЕРДОМ ТЕЛЕ И ПЛАЗМЕ

Influence of fourth-order anisotropy on precession of the magnetization equilibrium position under the conditions of orientational transition
Vlasov V.S., Shavrov V.G., Shcheglov V.I.
Abstract

The precession of the magnetization equilibrium position in a medium with uniaxial anisotropy of the second and fourth orders is considered. In the geometry of the normally magnetized ferrite plate the conditions of orientational transition necessary for excitation of precession of equilibrium are found. Time dependences of the fluctuations of the transverse components of the magnetization are obtained. Precession portraits for the cases of anisotropy of the second and fourth orders are constructed. It is shown that both of them have the form of a large ring filled along the formation by small rings. It is shown that at sufficiently large magnitude of the fourth-order anisotropy in the distribution of small rings, thickenings corresponding to fractures of the time dependences of the transverse magnetization components are observed.

Radiotehnika i èlektronika. 2024;69(12):1175-1182
pages 1175-1182 views

ТЕОРИЯ И МЕТОДЫ ОБРАБОТКИ СИГНАЛОВ

Neuromorphic decoding of sample image representations by the boundary-consistent interpolation method
Kershner V.A.
Abstract

The paper discusses methods for encoding and decoding large amounts of data using a neuromorphic model based on known neuromechanisms for the perception of visual information. Known mechanisms of the visual system, such as aggregation of counts by receptive fields, central-lateral inhibition, etc., have been studied. A decoding model has been developed that implements the function of simple cells of the primary visual cortex responsible for spatial perception of stimulus contrasts. The proposed decoding model makes it possible to restore local boundaries of objects in an image, while improving the visual quality of images in comparison with the quality of restoration with classical bilinear interpolation.

Radiotehnika i èlektronika. 2024;69(12):1183-1190
pages 1183-1190 views

НАНОЭЛЕКТРОНИКА

Features of nonequilibrium pinning of charge density waves in compounds HoTe3 and TmTe3
Voropaev D.M., Frolov A.V., Orlov A.P., Sinchenko A.A.
Abstract

In this paper, the similarity of glass systems with pinning in compounds with a charge density wave (CDW) TmTe3 and HoTe3 was investigated. For this purpose, the differential IVs in micro-bridge structures oriented along the sliding direction of the CDW, with a multi-stage temperature change, were studied. In such a system with a sliding CDW, the changing behavior of the threshold field during isothermal exposure was shown, with characteristic relaxation on a logarithmic time scale. A property characteristic of glass systems has been found – the memory effect, which allows us to assert the unusual glass nature of the system of pinning centers in this system.

Radiotehnika i èlektronika. 2024;69(12):1191-1197
pages 1191-1197 views

НОВЫЕ РАДИОЭЛЕКТРОННЫЕ СИСТЕМЫ И ЭЛЕМЕНТЫ

Designing and manufacturing of fractal elements based on a resistance-capacitance medium
Gil’mutdinov A.K., Maksimov K.O., Ushakov P.A.
Abstract

This work presents the experience of designing and manufacturing of fractal elements (FE) based on resistance capacitance media, in particular, based on a one-dimensional structurally uniform resistance-capacitance element with distributed parameters (RC-EDP) with R-C-NR (R-C-NR ЭРП) kind of a layer structure. It also presents the results of designing and manufacturing of thick film FE samples having constant phase of impedance –10°, –20°, –30° and –40° in the frequences range of 1.5 decade order. It gives the results of the comparative analysis of phase-frequency characteristics of the input impedance of the synthesized model and the manufactured sample.

Radiotehnika i èlektronika. 2024;69(12):1198-1205
pages 1198-1205 views
